Description
TL866II PLUS programmer is universal mcu BIOS eprom programmer. TL866II PLUS MCU BIOS Programmer support ICSP SPI in-circuit programming, TL866II PLUS MCU BIOS Programmer with 7pcs chip adapters.
XGecu TL866II PLUS EPROM Bios Programmer tl866cs AVR GAL PIC
support 15000+IC SPI Flash NAND EEPROM MCU PIC AVR replace TL866A TL866CS
TL866 programmer manufacturer,
Haikou Xingong Electronics Co., Ltd.
Official website:
www.xgecu.com/EN
www.autoelectric.cn/EN/
TL866II PLUS English manual download link:
www.xgecu.com/MiniPro/TL866II_Instructions.pdf
TL866II PLUS Latest software download link: (will be updated in the future)
forums.xgecu.com/viewthread.php?tid=20&page=1&extra=#pid23
(If you cannot download or downloading speed is very slow, please send message to us, we will send to your mail box)
TL866II PLUS Support Device List:
www.xgecu.com/MiniPro/TL866II_List.txt
MiniPro TL866II Programmer with 7pcs adapters and 1pcs PLCC BIOS Extractor pincer
Optional Package list:
Option 1 + 12pcs adapter
1 pcs x TL866A Programmer with 40pin ZIF
1 pcs x USB Cable
1 pcs x Installation CD with latest MiniPro software
1 pcs x PLCC32-DIP32 socket adapter
1 pcs x PLCC44-DIP44 socket adapter
1 pcs x 8SOP8 to DIP8 adapter (150mil)
1 pcs x 8SOP8 to DIP8 adapter (200mil)
1 pcs x PLCC IC extractor
1 pcs x PLCC44 to DIP40 socket adapter
1 pcs x PLCC28 to DIP24 socket adapter
1 pcs x PLCC20 to DIP20 socket adapter
1 pcs x TSSOP8 to SOP16 socket adapter...
Option 2:
1 pcs x TL866II Plus Programmer with 40pin ZIF
1 pcs x USB Cable
1 pcs x Installation CD with latest MiniPro software
- With Multi-functional ICSP interface
- 40pin ZIF socket, fully automatic, support fast mode SPI
- USB interface for both data transfer and power supply
- With over voltage and over current protection
- Supports the serial number of the chips two times development, built-in a variety of commonly used automatic numbering functions
- Multi-languages support capability: Chinese, English
- It can program faster than other programmer 500%~1000%
- Programming EPROM, EEPROM, FLASH, SPI, I2C,93Cxx, ICSP etc.
- Supports thousands of most popular application devices (13071+)
- Ideally suits the portable / convenient applications, that includes: car automotive field ECU chip tuning, airbag reset, mileage, satellite devices, BIOS refreshing, xBox, Wii gaming machines EPROM sync, PIC / MCU development, newer laptop technology and newer desktop PC etc.
- It has outstanding performance which supports the devices that other similar products are not capable: such as 25LF SPI series, PSOP44,TSOP48, 25VF SPI series, PLCC84, SST39VF3201, TE28F102, 27C1024, 27C1028, HD6475, 29F800, 29LV800, 29F032 etc.
- Software update regularly; free life-time software upgrade / download upgrade website: http://www.autoelectric.cn/minipro
MiniPro TL866A Features:
1. Neat robust enclosure; 40pin ZIF socket, fully automatic; Fast mode SPI support;
2. Support Windows 2000, XP, 2003, 2008, Vista & Win7(32/64),
3.USB interface for both data transfer and power supply;
4. High speed/fastest; user-friendly; simply-to-use;
5. Software update regularly; free life-time software upgrade/download;
6. Multi-languages support capability: Chinese, English;
7. Supports thousands of most popular application devices (12,000 +)
8. Ideally suits the portable/convenient applications that includes: car automotive field ECU chip tuning, airbag reset,mileage, satellite devices, BIOS refreshing, xBox, Wii gaming machines EPROM duplicate, PIC/MCU development, newer laptop technology and newer desktop PC etc.
9. It has outstanding performance which supports the devices that other similar products are not capable of supporting: such as 25LF SPI series, PSOP44,TSOP48, 25VF SPI series, PLCC84, SST39VF3201, TE28F102, 27C1024, 27C1028, HD6475, 29F800, 29LV800
Mini Pro TL866A Programmer chip supporting range:
* All kinds 26 27 28 29 37 39 49 50 Parallel ROM, EPROM, EEPROM
High-speed and wide-support
It can support TSOP32 TSOP40 TSOP48 chip to 64MBits and the programming speed is 5-10 times as fast as the similar.
* 24 25 35 45 85 93 95 Series EEPROM
It can widely support series chips and the 8-16 PIN 25 series chips can be supported to 64MBits capacity.
* Hundreds of the 51 series microcontroller
* AVR microcontroller, including ATMEGA series, ATtiny series, AT90XXX series microcontroller
AVR microcontroller can complete a one-to-one soft encryption by RC calibrating bytes.
It can support high-speed parallel programming and at the same time all AVR ATMEGAxxx chips can be supported SPI series download programming by using ICSP interface.
TQFP64, TQFP100PIN AMEGAxxx chips can be supported.
* Microchip PIC10 PIC12 PIC16 PIC18 Series microcontrollers:
As for PIC series chips, it can support more than 300 models and more than 900 types of packages. It is one of the most comprehensive programmer of supporting PIC chips. For all kinds of PIC chips, it can program with optimization and high speed strictly according to the manufacturer manual. For the majority of chips, it can support ISCP in-circuit programming and at the same time it can program by using programming socket.
* GAL programmable logic device programming
It can support the common PLD device.
* SRAM Test
It can support common 24 61 62 DS12 series SRAM test, respectively data line testing, the address line testing, memory cell incremental testing and unit testing.
* superb performance in 54/74F/LS/HC CMOS4000 series IC comprehensive function test:
This is the first development programmer that can test common logic IC. This test can locate the logic gate errors and get any possible input combinations of IC.
Programmable chips12700 +, the upgrade process will add more chip support.
At present, it can support more than 12700 chips and the types will gradually increase in the future upgrade.
Comparison between MiniPro TL866A and TL866CS programmer
http://www.vipprogrammer.com/news/comparison-between-minipro-tl866a-and-tl866cs-programmer-post-107.html
