Description
2021 Latest Xeltek SuperPro 7500 Universal Programmer, SuperPro 7500 is a High Speed 4 Gang Stand-Alone Universal Device Programmer. SuperPro 7000 is discontinued, replacement is the latest SuperPro 7500 programmer, which is a very powerful programming tool for eMMC / NAND flash memory, supports eMMC / NAND files up to 256 GB and Intel LR1 and LR2 eMMC modules (up to 64 GB).
Xeltek SuperPro 7500 programmer for eMMC / NAND flash memory(not including sockets).
The ultra powerful system engine allows to program either single or 4 chips simultaneously with equal ease. Convert the universal programmer into a 4 gang programmer just by inserting a 4-socket adapter. No need to buy an expensive gang programmer anymore and save thousands.
Super fast universal programmer with 144 pin drivers for the most complex device. It can program devices up to 256 GBytes faster than anything else on the market. It can operate in standalone mode with no PC, or it can be run in PC mode.
- Powerful programming processor supports eMMC / NAND files up to 256 GB
- Supports Intel LR1 and LR2 eMMC modules (up to 64 GB)
- Powerful new algorithm to program up to four chips simultaneously
- Customized 4-socket gang adapter + Programming algorithm(Optional)
- Devices user wants programmed could be added quickly
- New generation of pin-driver technology ensures higher reliability
- CE and RoHS Compliant
Three operating modes:
1. PC mode via USB2.0 port and PC communication.
2. Local Area Network (LAN) mode for access to LAN local or remote control
a) One or more units may be controlled by an operator for gang / cluster operation for volume programming. (Optional)
b) One unit may be shared by multiple users in a lab environment. (Optional)
c) A unit on the factory floor may be controlled remotely.
3. Stand-Alone mode (no PC required).Operates via built-in keyboard, LCD display and removable memory (standard SD card).
Setup is flexible and simple to expand (1-15 units) for large volume production on the factory floor. Projects files (limited only by SD card capacity limit) are created online and downloaded into the SD card.
Features:
- 144-pin Universal driver
- New pin-driver technology provides a cleaner signal, wider voltage range and more accurate clock frequency
- Universal adapters are available for various package types (up to 144 pins)
- Self-calibration improves chip security mechanism
- Automatic chip detection
- Improved overvoltage / overcurrent and ESD protection to avoid programmer damage
- Powerful yet user-friendly software features streamline operations, improve efficiency and reduce user mistakes during programming procedures
- Production mode start chip operation upon proper chip insertion
- Project function simplifies processes such as Device Selection, File Loading, Device Configuration Setting, Program Option, and Batch File Setting into one step
- Password can be set for project files
- Batch command combines device operations like Program, Verify, and Security into a single command at any sequence
- Serial number generator is available as standard or customer-specific functions
- Log file is useful for quality tracking
- Supports Windows XP / Vista / Win7
- XELTEK adds devices upon customer's request. General algorithm upgrades completed within a week
- Quick technical support
Hardware & electrical Specifications
- Devices Supported: EPROM, Paged EPROM, Parallel and Serial EEPROM, FPGA Configuration PROM, FLASH memory (NOR & NAND), BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU, etc...
- Package: DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP, SON, EBGA, FBGA, VFBGA, uBGA, CSP, SCSP, ...
- PC interface: USB2.0 (High speed)
- Stand-alone memory: Compact FLASH Card
- Power supply: AC Adapter: Input AC 90V- 250V; Output: 12V/1.5A; Power:15W
- Main unit: Dimensions 184(L) * 160(W) * 78(h) mm; Weight 1.8 lbs (0.8 Kg)
- Package: Dimensions 310(L) * 250(W) * 145(H) mm; Weight 3.6 lbs (1.65 Kg)
Package list:
SuperPro 7000 Programmer
EX0001 DIP48 Adapter
AC adapter
Software CD
USB Cable
Supported IC DEVICE LIST of SuperPro 7500 programmer
https://www.xeltek.com/software/sp7000/sp7000Device.php
